NetAtlas Enterprise 1.00 User’s Guide
Chapter 1 Introducing the EMS
42
Note: For information on the Window, Admin and Help options in the Switch
Manager screen, see
.
The EMS polls for all the available switch cards. Select a device icon to display a graphic of
the switch in the Device Panel. You can only display one switch in the Device Panel at one
time.
Figure 35 Switch Graphic Display
