NetAtlas Enterprise 1.00 User’s Guide
Chapter 2 EMS Main Window 44
C
H A P T E R
2
EMS Main Window
This chapter describes the EMS main window.
2.1 Introducing the EMS Main Window
After you have logged into the EMS, double-click the switch device icon in the Device List
Panel to display the EMS main screen (shown next). The EMS retrieves device information
from the switch (using SNMP protocol).
Figure 36 EMS Main Screen Overview
Device List Panel
Device Panel
System Message Panel
Menu Shortcut Bar
