The following table summarizes these sub-links in the navigation panel.
Table 8 EMS Navigation Panel Sub-link Descriptions
DESCRIPTION LABEL
MAP Screens
Add Submap/Device This link takes you to a screen where you can add a device or a submap
folder to the EMS Device List Panel.
Edit Node This link takes you to a screen where you can edit device properties.
Search Node This link takes you to a screen where you can search for a device or a
submap folder.
Delete Click this link to delete a submap folder or devices within a folder.
Refresh Click this link to update the screen with the most recently saved settings.
Template
VLAN Template This link takes you to a screen where you can pre-configure a template of
settings for upload to multiple devices.
Status Screens
Hardware Status This link takes you to a screen where you can view the hardware status of
a device.
STP Status This link takes you to a screen where you can view the software status of a
device.
VLAN Status This link takes you to a screen where you can view the VLAN status of a
device.
Port Status This link takes you to a screen where you can view the port status of a
device.
802.1d This link takes you to a screen where you can view the MAC addresses
(and types) of devices attached to what ports and VLAN IDs or view the
MAC addresses – IP address resolution table.
Performance
Interface This link takes you to a screen where you can configure interface
performance graphs and tables.
Fault Screens
Event Log This link takes you to a screen where you can configure an alarm filter.
Loopback Test This link takes you to a screen where you can perform a loopback test.
Maintenance
Firmware Upgrade This link takes you to a screen where you can perform a device firmware
upgrade.
Device Reset This link takes you to a screen where you can reset a device.
NE (Network Element)
Configuration Backup
and Restore
This link takes you to a screen where you can backup or restore
configuration files.
Load Factory Default This link takes you to a screen where you can load the factory default
settings.
Scheduled NE Config
Backup
This link takes you to a screen where you can schedule when you want to
backup a device configuration file.
Tool Screens
