NetAtlas Enterprise 1.00 User’s Guide
Chapter 13 Ethernet Port Configuration 132
5 Select the ports from the Port List Panel that you want to apply this configuration.
Figure 95 Configuration: Ethernet Port Configuration: Queue Method
The following table describes the fields in this screen.
Table 54 Configuration: Ethernet Port Configuration: Queue Method
LABEL DESCRIPTION
Q0 ~ Q7 Strictly Priority services queues based on priority only. When the highest
priority queue empties, traffic on the next highest-priority queue begins.
Q7 has the highest priority and Q0 the lowest.Weighted Fair Scheduling
is used to guarantee each queue’s minimum bandwidth based on their
bandwidth portion (weight) (the number you select from the drop-down
list box). Queues with larger weights get more guaranteed bandwidth
than queues with smaller weights.
Select a queue weight from the drop-down list box.
Apply Click Apply to save the changes back to the switch.
13.8 Port 802.1x
Use the following screen to configure reauthentication for selected ports.
13.8.1 Configuring Port 802.1x
Follow the steps below to configure the Port 802.1x screen.
1 In the Device Panel list, select a device and then right-click.
2 Click Configuration, Switch Configuration and then the Switch Setup tab.
3 Select the 802.1x check box and then click Apply.
4 Click Configuration, Ethernet Port Configuration and then the Port 802.1x tab.
