030-300233 Rev. A 14 May 2006
Westell (Models 6000, 6100, 6110) User Guide
5. Check to see if the Power LED is solid green. Solid green indicates that the modem power is ON.
6. Check to see if the DSL LED is solid green. If the DSL LED is solid green, the modem is functioning properly.
7. Check to see if the USB LED is solid green. Solid green indicates that the USB connection is functioning
properly.
8. Check to see if the Ethernet LED is solid green. Solid green indicates that the Ethernet connection is
functioning properly.
Congratulations! You have completed the simultaneous hardware (Ethernet and USB) installation for Models 6100
and 6110. Refer to your Internet service provider’s instructions for installing subscriber software and connecting to
the Internet. If you have a Model 6100 product, please proceed to section 7 to configure your Router for Internet
connection.
