030-300233 Rev. A
135
May 2006
User Guide
Westell Models (6000, 6100,6110)
19.2 Cable Connectors and Switch Locations
Model 6000
• DSL Connector (RJ-11)
• Ethernet Connector (RJ-45) (yellow)
• Power Connector
Model 6000-Rear View
Model 6100 and Model 6110
• DSL Connector (RJ-11)
• USB Connector (blue)
• Ethernet Connector (RJ-45) (yellow)
• Reset Button
• Power Connector
Model 6100 and Model 6110-Rear View
DSL Line
Connector
Power
Connector
Ethernet
Connector
USB
Connector
Reset
Button
DSL Line
Connector
Power
Connector
Ethernet
Connector
