Westell (Models 6000, 6100, 6110) User Guide
5.4 Installations
This section explains the procedures for installing via 10/100 Base-T/Ethernet, USB, or combined Ethernet and USB
connection.
IMPORTANT:
1. Please wait until you have received notification from your Internet service provider (ISP) that your DSL line
has been activated before installing your Modem.
2. If you are using a Westell Modem in conjunction with an Ethernet Hub or Switch, refer to the manufacturer’s
instructions for proper installation and configuration.
3. Westell recommends the use of a surge suppressor to protect equipment attached to the AC power supply.
4. Refer to Appendix B for additional information on the modems’ LED states.
5.4.1 Installation via 10/100 Base-T Ethernet (Models 6000, 6100, 6110)
NOTE: Before you connect via 10/100 Base-T, you must have an available Ethernet card installed in your
computer. If your Ethernet card does not auto-negotiate, you must set it to half duplex. Refer to the Ethernet card
manufacturer’s instructions for installing and configuring your Ethernet card.
1. Connect the power supply cord to the power connector marked on the rear panel of the Modem. Plug
the other end of the power supply into an AC wall socket.
2. Connect the DSL phone cable from the jack marked DSL on the rear panel of the Modem to the DSL-
equipped telephone line jack on the wall. IMPORTANT: Do not use a DSL filter on this connection. You must
use the phone cord that was provided with the kit.
3. Connect the yellow Ethernet cable from the yellow Ethernet jack marked ETHERNET on the rear panel
of the Modem to the Ethernet port on your computer.
4. Check to see if the Power LED is solid green. Solid green indicates that the modem power is ON.
5. Check to see if the DSL LED is solid green. If the DSL LED is solid green, the modem is functioning properly.
6. Check to see if the Ethernet LED is solid green. Solid green indicates that the Ethernet connection is
functioning properly.
For 6000 model users
7. Check the Power LED. Solid green indicates that the modem power is ON.
8. Check the Ready LED. Solid green indicates that the modem has synchronized with the ADSL line card.
9. Check the Link LED. Solid green indicates that the Ethernet connection is functioning properly.
10. Check the Activity LED. Solid green indicates that data is being sent or received on the Ethernet interface.
Congratulations! You have completed the Ethernet hardware installation. No software installation is required when
using only an Ethernet connection. Refer to your Internet service provider’s instructions for installing subscriber
software and connecting to the Internet. If you have a Model 6100 product, please proceed to section 7 to configure
your Router for Internet connection.
10.5 VAC
