15.6 USB Port Statistics
The following screen will be displayed if you select Troubleshooting > USB Stats from the main menu.
Number of Resets
The number of times the Host PC reset the USB interface.
Number of Isrs
The number of times the Host PC requested communication with the Router.
In Unicast Packets
The number of packets received that did not have a Multicast or Broadcast
class destination IP address.
In Non Unicast Packets
The number of packets received that had a Multicast or Broadcast class
destination IP address.
In Multicast Frames
The number of frames received that had a Multicast class destination IP
address.
In Broadcast Frames
The number of frames received that had a Broadcast class destination IP
address.
In Errors
The number of packets received with an invalid format
Out Good Frames
The number of frames sent to the Host PC.
Out Unicast Packets
The number of packets sent that did not have a Multicast or Broadcast class
destination IP address
Out Non Unicast Packets
The number of packets sent that had a Multicast or Broadcast class
destination IP address.
Out Multicast Frames
The number of frames sent that had a Multicast class destination IP address.
Out Broadcast Frames
The number of frames sent that had a Broadcast class destination IP address.
Out Errors
The number of packets received by the Router but not sent to PC due to an
error condition.
