030-300233 Rev. A
136
May 2006
User Guide
Westell Models (6000, 6100,6110)
19.3 Connector
Descriptions
The following table displays the connector types.
SYMBOL
N
AME
T
YPE
F
UNCTION
DSL LINE
6-pin RJ-11 modular jack
Connects to an ADSL-equipped telephone jack or
DSL connection of a POTS splitter.
USB
4-pin USB Series B connector
Connects the USB device to the PC.
10.5 VAC
POWER
Barrel connector
Connection to AC (10.5 V) power connector.
ETHERNET 8-pin (RJ-45) modular jack
10/100 Base-T Ethernet connection to PC or Hub.
19.4 Pinout
Descriptions
The following tables list the pinout descriptions.
DSL Pinouts
Pinout
Description
1, 2, 5, 6
Not Used
3 DSL
Tip
4 DSL
Ring
USB Series B Connector Pinouts
Pin
Name
Description
Cable Color
1 VBUS/Vcc 5
Vdc
Red
2
D –
Data –
White
3
D +
Data +
Green
4 GND Ground Black
Ethernet Pinouts
Pinout
Description
1 Rx+
2 Rx-
3 Tx+
4,5,7,8 Not
Used
6 Tx-
