Instruction Set
3-19 RISC 16-Bit CPU
3.4.2 Single-Operand (Format II) Instructions
Figure 3−10 illustrates the single-operand instruction format.
Figure 3−10. Single Operand Instruction Format
B/W D/S-Reg
15 0
Op-code
8 7 14 13 12 11 10 9 6 5 4 3 2 1
Ad
Table 3−12 lists and describes the single operand instructions.
Table 3−12.Single Operand Instructions
Mnemonic S-Reg, Operation Status Bits
D-Reg
V N Z C
RRC(.B) dst C → MSB → .......LSB → C * * * *
RRA(.B) dst MSB → MSB → ....LSB → C 0 * * *
PUSH(.B) src SP − 2 → SP, src → @SP − − − −
SWPB dst Swap bytes − − − −
CALL dst SP − 2 → SP, PC+2 → @SP − − − −
dst → PC
RETI TOS → SR, SP + 2 → SP * * * *
TOS → PC,SP + 2 → SP
SXT dst Bit 7 → Bit 8........Bit 15 0 * * *
* The status bit is affected
− The status bit is not affected
0 The status bit is cleared
1 The status bit is set
All addressing modes are possible for the CALL instruction. If the symbolic
mode (ADDRESS), the immediate mode (#N), the absolute mode (&EDE) or
the indexed mode x(RN) is used, the word that follows contains the address
information.
