Timer_A Registers
12-23 Timer_A
CCIE Bit 4 Capture/compare interrupt enable. This bit enables the interrupt request of
the corresponding CCIFG flag.
0
Interrupt disabled
1 Interrupt enabled
CCI Bit 3 Capture/compare input. The selected input signal can be read by this bit.
OUT Bit 2 Output. For output mode 0, this bit directly controls the state of the output.
0
Output low
1 Output high
COV Bit 1 Capture overflow. This bit indicates a capture overflow occurred. COV must
be reset with software.
0
No capture overflow occurred
1 Capture overflow occurred
CCIFG Bit 0 Capture/compare interrupt flag
0
No interrupt pending
1 Interrupt pending
TAIV, Timer_A Interrupt Vector Register
15 14 13 12 11 10 9 8
0 0 0 0 0 0 0 0
r0 r0 r0 r0 r0 r0 r0 r0
7 6 5 4 3 2 1 0
0 0 0 0 TAIVx 0
r0 r0 r0 r0 r−(0) r−(0) r−(0) r0
TAIVx Bits
15-0 Timer_A Interrupt Vector value
TAIV Contents Interrupt Source Interrupt Flag
Interrupt
Priority
00h No interrupt pending −
02h Capture/compare 1 TACCR1 CCIFG Highest
04h Capture/compare 2 TACCR2 CCIFG
06h Capture/compare 3 † TACCR3 CCIFG
08h Capture/compare 4 † TACCR4 CCIFG
0Ah Timer overflow TAIFG
0Ch Reserved −
0Eh Reserved − Lowest
† Timer1_A5 only
