Timer_A Registers
12-22 Timer_A
TACCTLx, Capture/Compare Control Register
15 14 13 12 11 10 9 8
CMx CCISx SCS SCCI Unused CAP
rw−(0) rw−(0) rw−(0) rw−(0) rw−(0) r−(0) r−(0) rw−(0)
7 6 5 4 3 2 1 0
OUTMODx CCIE CCI OUT COV CCIFG
rw−(0) rw−(0) rw−(0) rw−(0) r rw−(0) rw−(0) rw−(0)
CMx Bit
15-14 Capture mode
00
No capture
01 Capture on rising edge
10 Capture on falling edge
11 Capture on both rising and falling edges
CCISx Bit
13-12 Capture/compare input select. These bits select the TACCRx input signal.
See the device-specific datasheet for specific signal connections.
00
CCIxA
01 CCIxB
10 GND
11 V
CC
SCS Bit 11 Synchronize capture source. This bit is used to synchronize the capture input
signal with the timer clock.
0
Asynchronous capture
1 Synchronous capture
SCCI Bit 10 Synchronized capture/compare input. The selected CCI input signal is
latched with the EQUx signal and can be read via this bit
Unused Bit 9 Unused. Read only. Always read as 0.
CAP Bit 8 Capture mode
0
Compare mode
1 Capture mode
OUTMODx Bits
7-5 Output mode. Modes 2, 3, 6, and 7 are not useful for TACCR0 because EQUx
= EQU0.
000 OUT bit value
001 Set
010 Toggle/reset
011 Set/reset
100 Toggle
101 Reset
110 Toggle/set
111
Reset/set
