56
Converting from Previous Models
Section 2-12
■
Window Display in ETN11 Mode
■
Checking by Reading Words Allocated in the CIO Area
Changing the CPU Bus
Unit System Setup Area
Format
The CPU Bus Unit System Setup Area format can be changed in either of the
following two ways. Select the method that can be used in the system in which
the Unit is to be replaced.
• By means of the CX-Programmer's Unit Setup
• By manipulating the rotary switches for the node address with a precision
screwdriver
Bit address
Format classification
11
10
9
8
0
0
0
0
ETN11 mode
0
0
0
1
ETN21 mode
Other
Reserved
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
n+17
System Setting Format
