Page 62
62
Chapter 3 Viewing the BCM50 system LEDs
NN40020-302
The table
System status LEDs states and descriptions
on page 62 describes the meaning of the
system status LEDs after the system boots up and is in service.
During BCM50 system startup or reboot, the system status LEDs move through a sequence of state
changes. If either the power LED or status LED is yellow, the system is initializing and is not
ready for service. The table
System status LEDs during startup or reboot
on page 62 shows the key
states indicating service availability.
LAN port LEDs
Each LAN port on the main unit and expansion unit has two LEDs. These LEDs indicate the status
of the connection for that LAN port. The figure
on page 63 shows the
location of these LEDs on the main units and expansion unit.
Table 8 System status LEDs states and descriptions
Power
Status
Description
Solid green
Solid green
Normal operation.
Solid green
Solid red
A Major or Critical alarm is activated on the BCM50.
You must clear the status LED using the Element Manager Alarm Panel.
The LED does not clear itself.
See the Administration Guide for more information.
Flashing green
Solid green
Contact technical support (see
Off
Off
No power to BCM50.
Table 9 System status LEDs during startup or reboot
Power
Status
Description
Solid yellow
Any
System initializing; not ready for service.
Flashing or solid
green
Flashing or
solid yellow
System initializing; not ready for service.
Flashing green
Flashing green
BCM50 telephony services are available, including IP telephony and
voice mail.
Solid green
Flashing green
Administrator can log into BCM50 with Element Manager.
Solid green
Solid green
All BCM50 services are functioning, and the system is ready for normal
use.
Note: The expansion ports on the main unit also function as LAN ports. The
expansion port LEDs indicate LAN activity only. The LEDs do not indicate
expansion unit presence. The LEDs do not light.
