Cooling fan, Hard disk and bracket – Nortel Networks BCM50 User Manual
Page 53
Chapter 2 Introducing the BCM50 hardware
53
Installation and Maintenance Guide
Figure 23 Hard disk and bracket
Cooling fan
The main units have one cooling fan. The expansion unit has two cooling fans. See the figure
Figure 24 Cooling fan
The cooling fan mounts in the back of the BCM50 enclosure.
For information about how to install or replace the cooling fan, see
Hard disk
bracket
Hard disk
fan connector
