Setting Up Your Modular Server 3-17
USB Connection by SUV Cable
Connect the floppy disk drive, DVD-ROM drive, keyboard, and mouse according to the figure
shown below.
The USB hub should have the self-power specification if it is used.
External DVD-ROM drive
Mouse
Keyboard
USB
USB
Display unit
External floppy disk drive
Self-powered
USB hub
Display unit
USB
USB
External DVD-ROM drive
Mouse
Keyboard
