Managing Intelligent Multicasting (Layer 2 & Layer 3)
15-14 Cajun P550/P220 Switch Operation Guide
3. Click...
• APPLY to save your changes.
• CANCEL to restore previous settings.
• CLEAR to clear the statistics.
• REFRESH to refresh the contents of the table.
Modifying the LGMP Server Display per VLAN
To modify the LGMP server display per VLAN:
1. In the Intelligent Multicasting section of the Web Agent window, click LGMP
Server. The LGMP Server Configuration dialog box opens.
Note: You must enable intelligent multicasting on a global basis to make your LGMP
server per VLAN configuration active.
2. In the LGMP Servers column, click the number. The LGMP Server Display per
VLAN opens.
LGMP Message
Transmission Statistics • Report - Displays the number of LGMP report
messages transmitted.
• Leave - Displays the number of LGMP leave messages
transmitted.
• End Session - Displays the number of LGMP end
session messages transmitted.
• Router Report - Displays the number of LGMP router
report messages transmitted.
• Router Leave - Displays the number of LGMP router
leave messages transmitted.
Intelligent Multicast
Session Statistics • Client Ports Added- Displays the number of add
client events generated by LGMP.
• Client Ports Removed - Displays the number of
remove client events generated by LGMP.
• Sessions Removed- Displays the number of remove
session events generated by LGMP.
• Router Ports Added- Displays the number of add
router events generated by LGMP.
• Router Ports Removed- Displays the number of
remove router events generated by LGMP.
Table 15-9. LGMP Server Configuration Parameters (Continued)
Parameter Definition
