Configuring IP Routing (Layer 3)
7-40 Cajun P550/P220 Switch Operation Guide
3. Use Table 7-27 to review the DVMRP Multicast Forwarding Cache information:
4. In the Upstream Interface is Pruned field, click on the number to view
information on the upstream prune information. The Upstream Prune Information
dialog box opens.
5. Use Table 7-28 for more information on upstream prunes.
Table 7-27. DVMRP Multicast Forwarding Cache Parameters
Parameter Defines the...
Select Selection of the multicast forwarding cache.
Destination Group
Address Destination group address of the multicast transmission.
Source SubNetwork Subnet from which the flow is coming.
Source Address Mask Subnet mask associated with the DVMRP source subnetwork.
Upstream Interface Local interface which is receiving this flow.
Upstream Neighbor
(Router) Address IP address of the upstream neighbor (router).
Invalid Flows From
Upstream Number of invalid flows received from the upstream neighbor.
Packets Forwarded
Through Cache Entry Number of packets successfully forwarded in the CPU
(supervisor module) for this flow.
Upstream Interface is
Pruned Router that is sending prunes to the upstream neighbor. Allows
you to open the DVMRP Upstream Prune Information dialog
box.
Next Pruned
Downstream Interface to
Timeout Next interface that is currently pruned which will be grafted
back.
Downstream Interface(s) Number of downstream interfaces. Allows you to open the
DVMRP Downstream Links dialog box.
Upstream Source(s) Number of upstream interfaces. Allows you to open the
Upstream Sources dialog box.
