Configuring AppleTalk Routing (Layer 3)
Cajun P550/P220 Switch Operation Guide
10-11
Adding or Deleting Interfaces to a Zone Filter
To add or delete interfaces to a zone filter:
1. In the AppleTalk Configuration section of the Web Agent window, click Zone
Filter. The AppleTalk Zone Filter dialog box opens.
2. Click Edit If. The Add/Delete Interface to Zone Filter dialog box opens.
3. In the Add pull-down menu, select the interface to be added.
Or
Click the Select for the interface to be removed.
4. Click...
Add to add this zone filter to the selected interface.
DELETE to remove this zone filter from the selected interface.
CANCEL to restore previous settings.
Viewing AppleTalk Statistics
This section includes:
❒ Viewing AppleTalk Global Statistics
❒ Viewing the AppleTalk Interface Statistics Table
❒ Viewing the AppleTalk Route Table
❒ Viewing AppleTalk Route Table Statistics
❒ Viewing the AppleTalk ARP Cache Table
❒ Viewing the AppleTalk Zone Table
❒ View AppleTalk Zone Table Statistics
❒ Viewing the AppleTalk NBP Table
Viewing AppleTalk Global Statistics
To view AppleTalk global statistics:
1. In the AppleTalk Display section of the Web Agent window, click Global
Statistics. The AppleTalk Global Statistics dialog box opens.
