PinPoint X HSDPA
55
20070914
Figure 7-4: I/O Wiring Harness, AirLink part number 120-140-1014
Figure 7-5: Color Corospondance to connection points
Analog Inputs
Connect a wiring lead to an analog input (AIN) at 1, 3, 12 or 14,
and the nearest ground at 2 or 13.
Table 7-2: Wiring Color Corospondance
1.
Violet/Red
12.
Violet/Black
2.
Black/Red
13.
Black/White
3.
Violet/Green
14.
Violet/White
4.
none
15.
none
5.
none
16.
none
6.
Yellow/White
17.
Green/White
7.
Yellow/Black
18.
Green/Black
8.
none
19.
none
9.
Orange/Red
20.
Orange/Black
10.
Black/Green
21.
Black/Brown
11.
Orange/Green
22.
Orange/White
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
none
none
none
none
O/W
V/R
V/Bl
Bl/R
Bl/W
V/G
V/W
Y/W
G/W
Y/Bl
G/Bl
O/R none
none
O/Bl
Bl/G
Bl/Br
O/G
