Hardware Installation of the PinPoint X
Rev 3.0B Feb.08 26
• The Reset button (on the left side of the PinPoint X) has
two functions. If it is quickly depressed and released, the
modem will simply power cycle the internal hardware. If,
however, the reset is depressed and held for several
seconds (count 10 slowly, and wait for the power light to
go off after the light pattern stops), the ALEOS configu‐
ration settings will return to the factory defaults.
Light Patterns
The LEDs on the front of the modem will respond in different
patterns to indicate modem states.
• Normal ‐ Each LED, mentioned above, lit as applicable.
• Start up ‐ The LEDs will cycle from left to right.
• PassThru mode ‐ Network and Signal LEDs will blink in
tandem. The Activity LED will blink when transmitting or
receiving data.
• SOS ‐ The Network Chan and Service Err or Serv LEDs
will blink alternate to each other.
• Low Power ‐ All LEDs will be off except the power LED
which will blink every 3 seconds.
• Configuration Reset ‐ The LEDs will cycle left to right and
then right to left 4 times.
• Authentication Failure ‐ The Network, Signal, and
Activity LEDs blink every 2 seconds.
• Data Retry ‐ The Network, Signal, and Activity LEDs blink
every 3 seconds.
• Invalid MAC Address or Ethernet Initiation Fail ‐ The
Service LED will blink.
Mounting
The integrated mounting with keyhole screw mounts on the
PinPoint X will allow you to secure your modem nearly
anywhere, quickly and easily, without the need for a separate
bracket.
Caution: If you reset the modem configuration using the reset button,
you may to reconfigure your APN.
