Global Positioning System (GPS)
Rev 3.0B Feb.08 97
Support for a COM1000 is enable with the command
*PPCOM1000=1 or *PPREPORTINPUTS=1. Once enabled,
ALEOS will receive the reports from a properly configured
COM1000 and add the state of the extra inputs to RAP packets
sent to the RAP Host.
Figure 10-22: AceManager : *PPCOM1000, *PPREPORTINPUTS
If you are replacing an existing Pinpoint or PinPoint‐E in a
vehicle with a COM1000, simply replace earlier modem with
the with the PinPoint. Turn on COM1000 reporting with the
command *PPCOM1000=1 to allow a seamless transition with
no need to change any commands to support the COM1000 in
the same operation as the previous installation.
If you have a new vehicle installations for the PinPoint and
have previously installed Pinpoints or PinPoint‐E modems
plus COMM1000 in other vehicles, connect the inputs directly
to the PinPoint and turn on input reporting with the command
*PPREPORTINPUTS=1. Since the PinPoint inputs report using
the exact same bit fields as the COM1000, no changes to your
software should be required.
Caution: If both *PPCOM1000 and *PPREPORTINPUTS are
enabled, the PinPoint X digital inputs will be reported and the
COM1000 inputs will be ignored.
The report type will indicate the state of change in the inputs.
The contents of the report will be the same as Report Type 0x12
(GPS data with date) or 0x13 (GPS data with date and RF data)
with the addition of the event report.
Flush on Event
If you have Store and Forward configured and enabled, to
receive event reports immediately when they occur, you will
want to enable *PPFLUSHONEVT. This will cause all pending
reports, including the triggering event, to be sent immediately
to the Host.
Figure 10-23: AceManager : *PPFLUSHONEVT
