Configuration Commands
Rev 3.0B Feb.08 158
Figure 1-20: AceManager : I/O
*ANALOGINn?
Query individual analog inputs. The analog inputs report the voltage
in volts.
• n=1‐4 Input number
*DIGITALINn?
Query individual digital inputs. The digital inputs report
either a 0 (open) or 1 (closed).
• n=1‐4 Input number
*IOSTATE=n,s
Query the full set of digital inputs, analog inputs, and relay
outputs, or set the relay outputs.
• n=1‐4 Input number
• s=OPEN or CLOSED
When you query the inputs (AT*IOSTATE?), they will all be
listed with their current state. Example:
DI1 OPEN
DI2 CLOSED
DI3 OPEN
DI4 OPEN
DO1 OPEN
DO2 CLOSED
AI1 0.35 volts
AI2 12 volts
AI3 6.8 volts
AI4 1.3 volts
*RELAYOUTn=x
Set or query the relay outputs.
