IBM Oce TDS800 - Manual (Page 262)

262 Océ TDS800 User Manual
Safety data sheet Océ TDS800 scanner
The content of this safety data sheet is subject to the disclaimer of liability on
page 260 of this manual.
PRODUCT SAFETY DATA SHEET
Number E-729-a-UK
Date January 2001
Copyright © 2001 Océ-Technologies B.V., Venlo, NL
Model Océ TDS800 Scanner
Description Freestanding scanner, maximum original size 1036 mm x 6000 mm
Max. process speed 10 m/min
Dimensions Width 1320 mm
Depth 640 mm
Height 1235 mm
Weight 147 kg
Voltage 230 V
Frequency 50 Hz
Current-rated 1 A
Power consumption,stand by 165 W
Power consumption, operation 180 W at continuous operation
EPA ENERGY STAR ®
* Power consumption low power 7 W
Mains connection Cable with plug
Safety class I (IEC 536) Protective earth connection
Protection class IP 20 (IEC 529)
Sound pressure level
(at operator position)
Stand byIn operation
43 dB(A)main body 53 dB(A)
impulse
L i = 9 dB(A)
Sound power level 56 dB(A)main body 68 dB(A)
Radio interference Complies with Directive 89/336/EEC and FCC rules and regulations, part 15 Class A.
Radiation Below the Threshold Limit Values for UV, Visible and IR radiation (TLV list of ACGIH)
Heat emission Standby165 W; at continuous operation 180 W
Ozone emission Not applicable
Room volume No special requirements
Room ventilation
Consumables Not applicable
Additional safety information None
CE-Compliance Approved according to Approved according to EPA ENERGY STAR ®
Low Voltage Directive EMC Directive
73/23/EEC 89/336/EEC
