240
APPENDIX A DEVELOPMENT TOOLS
A.5 System-Upgrade Method from Other In-Circuit Emulators to 78K/0 Series In-Circuit Emulator
If you already have an in-circuit emulator for the 78K series or the 75X/XL series, you can use that in-circuit emulator
as the equivalent of the 78K/0 series in-circuit emulator IE-78000-R or IE-78000-R-A by replacing the internal break
board with the IE-78000-R-BK.
Table A-1. System-Up Method from Other In-Circuit Emulator to IE-78000-R
Series Name In-Circuit Emulator Owned Board to be Purchased
75X/XL series IE-75000-R Note , IE-75001-R IE-78000-R-BK
78K/I series IE-78130-R, IE-78140-R
78K/II series IE-78230-R Note , IE-78230-R-A,
IE-78240-R Note , IE-78240-R-A
78K/III seires IE-78320-R Note , IE-78327-R,
IE-78330-R, IE-78350-R
Note Maintenance product
Table A-2. System-Up Method from Other In-Circuit Emulator to IE-78000-R-A
Series Name In-Circuit Emulator Owned Board to be Purchased
75X/XL series IE-75000-R Note 1 , IE-75001-R IE-78000-R-BK Note 2
78K/I series IE-78130-R, IE-78140-R
78K/II series IE-78230-R Note 1 , IE-78230-R-A,
IE-78240-R Note 1 , IE-78240-R-A
78K/III seires IE-78320-R Note 1 , IE-78327-R,
IE-78330-R, IE-78350-R
78K/0 series IE-78000-R — Note 2
Notes 1. Maintenance product
2. Partial remodeling of the frame of the in-circuit emulator and replacement of the control/
trace board with a supervisor board must be done by NEC.
