CHAPTER 11 SERIAL INTERFACE CHANNEL 2
PE
6 5 4 3 2 1 0 7
Symbol
ASIS 0 0 0 0 0 FE OVE FF71H 00H R
Address After Reset R/W
OVE
0
1
Overrun Error Flag
Overrun error not generated
Overrun error generated Note 1
(When next receive operation is completed before
data from receive buffer register is read)
FE
0
1
Framing Error Flag
Framing error not generated
Framing error generated Note 2
(When stop bit is not detected)
PE
0
1
Parity Error Flag
Parity error not generated
Parity error generated (When transmit data parity
does not match)
(c) Asynchronous serial interface status register (ASIS)
ASIS is set with a 1-bit or 8-bit memory manipulation instruction.
RESET input sets ASIS to 00H.
Notes 1. The receive buffer register (RXB) must be read when an overrun error is generated. Overrun
errors will continue to be generated until RXB is read.
2. Even if the stop bit length has been set as 2 bits by bit 2 (SL) of the asynchronous serial
interface mode register (ASIM), only single stop bit detection is performed during reception.
