234
APPENDIX A DEVELOPMENT TOOLS
A.2 PROM Programming Tools
A.2.1 Hardware
PG-1500 This is a PROM programmer capable of programming the single-chip microcontroller with on-chip
PROM programmer PROM by manipulating from the stand-alone or host machine through connection of the
separately available programmer adapter and the attached board. It can also program separate
PROM ICs with a capacity from 256 Kbits to 4 Mbits.
PA-78P083CU This is a PROM programmer adapter for the
µ
PD78P083, and is used connected to the PG-1500.
PA-78P083GB PA-78P083CU: 42-pin plastic shrink DIP (600 mil)
PROM programmer 42-pin ceramic shrink DIP (with window) (600 mil)
adapter PA-78P083GB: 44-pin plastic QFP (10
×
10 mm)
A.2.2 Software
PG-1500 controller This program controls the PG-1500 from the host machine through serial and/or parallel interface
cable(s).
Part Number:
µ
S
ЧЧЧЧ
PG1500
Remark
ЧЧЧЧ
of the part number differs depending on the host machine and OS used. Refer to the table below.
µ
S
ЧЧЧЧ
PG1500
ЧЧЧЧ Host Machine OS Medium
5A13 PC-9800 Series MS-DOS 3.5-inch 2HD
5A10 (Ver. 3.30 to 6.2 Note ) 5-inch 2HD
7B13 IBM PC/AT and their Refer to A.4 3.5-inch 2HC
7B10 compatible machines 5-inch 2HC
Note The task swap function is not available with this software through the function is
provided in MS-DOS version 5.0 or later.
