235
APPENDIX A DEVELOPMENT TOOLS
A.3 Debugging Tools
A.3.1 Hardware
IE-78000-R-A This in-circuit emulator helps users in debugging hardware and software of an application system
In-circuit emulator that includes a 78K/0 series device. This in-circuit emulator supports integrated debugger
(supporting integrated (ID78K0). It is used with emulation probe and interface adapter that connects host machine.
debugger)
IE-70000-98-IF-B This is an adapter necessary when using the PC-9800 series (except notebook type) as a host
Interface adapter machine for the IE-78000-R-A.
IE-70000-98N-IF This is an adapter and cable necessary when using notebook type PC-9800 series as a host
Interface adapter machine for the IE-78000-R-A.
IE-70000-PC-IF-B This is an adapter necessary when using IBM PC/AT as a host machine for the IE-78000-R-A.
Interface adapter
IE-78000-R-SV3 This is an adapter and cable necessary when using EWS as a host machine for the IE-78000-R-
Interface adapter A.
As Ethernet™, 10Base-5 is supported. With other mode, commercially available conversion
adapter is necessary.
IE-78000-R This is in-circuit emulator that debugs hardware and software when application system using
In-circuit emulator 78K/0 series is developed. It supports screen debugger (SD78K/0), and is used with emulation
(supporting screen probe. This emulator is connected to host machine or PROM programmer for efficient
debugger) debugging.
IE-78078-R-EM This board is used to emulate device-specific peripheral hardware (3.0 to 5.5 V), and is used with
Emulation board in-circuit emulator.
IEP-78083CU-R This is a probe to connect an in-circuit emulator to target sytem.
Emulation probe This probe is designed for 42-pin plastic shrink DIP (CU type) and 42-pin ceramic shrink DIP
(DU type).
EP-78083GB-R This is a probe to connect an in-circuit emulator to target system.
Emulation probe This probe is designed for 44-pin plastic QFP (GB-3B4, GB-3BS-MTX types).
This probe set includes a 44-pin conversion socket EV-9200G-44 for easier development of
target systems
EV-9200G-44 This adapter connects the EP-78083GB-R to the target system board designed for 44-pin plastic
Conversion socket QFP (GB-3B4, GB-3BS-MTX types).
Remark EV-9200G-44s are sold in sets of five units.
