97
CHAPTER 6 8-BIT TIMER/EVENT COUNTERS 5 AND 6
Figure 6-14. PWM Output Operation Timing (Active high setting)
Remark n = 5, 6
Figure 6-15. PWM Output Operation Timings (CRn0 = 00H, active high setting)
Remark n = 5, 6
Count Clock
TMn Count Value
CRn0
TCEn
INTTMn
TOn
01 02 FF 00 01 02 N N+1 N+2 N+3 00
OVFn
M N N
00
Inactive Level
CRn0 Changing
(M
→
N)
Active Level
Inactive Level
Inactive Level
Count Clock
TMn Count Value
CRn0
TCEn
INTTMn
TOn
01 02 FF 00 01 02 FF 00 01 02 00
OVFn
M 00 00
00
Inactive Level
CRn0 Changing
(M
→
00)
Inactive Level
