Technical Specifications A-7
A.4.2 AP-5181 Antenna Specifications
The AP-5181 2.4 GHz antenna suite includes the following models:
LAK1 RPBNC-F N-F 0.305 RG-58
LAK2 N-F N-M
10JK N-M N-M 3.05 RG-8
25JK N-M N-M 7.62 RG-8
50JK N-M N-M 15.24 RG-8
100JK N-M N-M 30.48 RG-8
Part Number Antenna Type
Nominal Net Gain
(dBi) Description
ML-2499-FHPA5-01R Omni-Directional Antenna 5.0 2.4 GHz,
Type N connector,
no pigtail
ML-2499-FHPA9-01R Omni-Directional Antenna 9.0 2.4 GHz,
Type N connector,
no pigtail
ML-2452-PNA7-01R Panel Antenna (Dual-Band) 8.0 2.4 - 2.5/4.9 - 5.99
GHz, 66 deg/60 deg
Type N connector,
with pigtail
ML-2452-PNA5-01R Sector Antenna (Dual-Band) 6.0 2.3 - 2.4/4.9 - 5.9 GHz,
120 deg Sector
Type N connector,
with pigtail
Item Connector1 Connector2 Length (meters) Cable Type
