Hardware Installation 2-9
The AP-5181 5.2 GHz antenna suite includes the following models:
2.5 Power Options
2.5.1 AP-5131 Power Options
The power options for the AP-5131 include:
• Power Injector (Part No. AP-PSBIAS-1P2-AFR)
• 48-Volt Power Supply (Part No. 50-14000-243R)
• Any standard 802.3af compliant device.
ML-2452-PNA7-01R Panel Antenna (Dual-Band) 8.0 2.4 - 2.5/4.9 - 5.99
GHz, 66 deg/60 deg
Type N connector,
with pigtail
ML-2452-PNA5-01R Sector Antenna (Dual-Band) 6.0 2.3 - 2.4/4.9 - 5.9 GHz,
120 deg Sector
Type N connector,
with pigtail
Part Number Antenna Type
Nominal Net Gain
(dBi) Description
ML-5299-FHPA6-01R Omni-Directional Antenna 7.0 4.900-5.850 GHz,
Type N connector,
no pigtail
ML-5299-FHPA10-01R Omni-Directional Antenna 10.0 5.8 GHz,
Type N connector,
no pigtail
Part Number Antenna Type
Nominal Net Gain
(dBi) Description
