AP-51xx Access Point Product Reference Guide 6-38
If access point #1 has the following values:
• WAN IP address: 20.1.1.2
• LAN IP address: 10.1.1.1
• Subnet Mask: 255.0.0.0
Then, the VPN values for access point #2 should be:
• Remote subnet: 10.1.1.0 or 10.0.0.0
• Remote subnet mask: 255.0.0.0
• Remote gateway: 20.1.1.2
3. If a VPN tunnel has been added to the list of available access point tunnels, use the VPN
Tunnel Config field to optionally modify the tunnel’s properties.
Tunnel Name The Tunnel Name column lists the name of each VPN tunnel on
the access point .
Remote Subnet The Remote Subnet column lists the remote subnet for each
tunnel. The remote subnet is the subnet the remote network uses
for connection.
Remote Gateway The Remote Gateway column lists a remote gateway IP address
for each tunnel. The numeric remote gateway is the gateway IP
address on the remote network the VPN tunnel connects to. Ensure
the address is the same as the WAN port address of the target
gateway AP or switch.
Key Exchange Type The Key Exchange Type column lists the key exchange type for
passing keys between both ends of a VPN tunnel. If Manual Key
Exchange is selected, this column displays Manual. If Auto (IKE)
Key Exchange is selected, the field displays
Automatic .
NOTE When creating a tunnel, the remote subnet and remote subnet mask must
be that of the target device’s LAN settings. The remote gateway must be
that of the target device’s WAN IP address.
Tunnel Name Enter a name to define the VPN tunnel. The tunnel name is used to
uniquely identify each tunnel. Select a name best suited to that
tunnel’s function so it can be selected again in the future if required
in a similar application.
