Motorola AP-51XX User Manual
Page 604
AP-51xx Access Point Product Reference Guide
9-16
If the Client Bridge checkbox has been selected, use the
Mesh Network Name
drop-down
menu to select the WLAN (ESS) the client bridge uses to establish a wireless link. The
default setting, is (WLAN1). Motorola recommends creating (and naming) a WLAN
specifically for mesh networking support to differentiate the Mesh supported WLAN from
non-Mesh supported WLANs. For more information, see
Networking Support on page 9-9
Once the settings within the Radio Configuration screen are applied (for an initial
deployment), the current number of base bridges visible to the radio displays within the
BBs
Visible
field, and the number of base bridges currently connected to the radio displays
within the
BBs Connected
field. If this is an existing radio within a mesh network, these
values update in real-time.
6.
Click the
Advanced
button to define a prioritized list of access points to define mesh
connection links.
7.
Select the
Automatic Link Selection
checkbox to allow the access point to select the links
used by the client bridge to populate the mesh network. Selecting this checkbox prohibits
NOTE
Ensure you have verified the radio configuration for both Radio 1 and
Radio 2 before saving the existing settings and exiting the Radio
Configuration screen.v
