Hardware Installation 2-17
For standard 48-Volt Power Adapter (Part No. 50-14000-243R) and line cord installations:
a. Connect RJ-45 Ethernet cable between the network data supply (host) and the AP-5131
LAN port.
b. Verify the power adapter is correctly rated according the country of operation.
c. Connect the power supply line cord to the power adapter.
d. Attach the power adapter cable into the power connector on the AP-5131.
e. Plug the power adapter into an outlet.
9. Verify the behavior of the AP-5131 LEDs. For more information, see AP-5131 LED Indicators
on page 2-23 .
The AP-5131 is ready to configure. For information on an AP-5131 default configuration, see
Getting Started on page 3-1 . For specific details on AP-5131 system configurations, see
System Configuration on page 4-1 .
2.7.3 Suspended Ceiling T-Bar Installations
A suspended ceiling mount requires holding the AP-5131 up against the T-bar of a suspended ceiling
grid and twisting the AP-5131 chassis onto the T-bar.
The mounting hardware and tools (customer provided) required to install the AP-5131 on a ceiling
T-bar consists of:
• Safety wire (recommended)
• Security cable (optional)
To install the AP-5131 on a ceiling T-bar:
1. If required, loop a safety wire —with a diameter of at least 1.01 mm (.04 in.), but no more
than 0.158 mm (.0625 in.) —through the tie post (above the AP-5131’s console connector)
and secure the loop.
2. If required, install and attach a security cable to the AP-5131 lock port.
3. Attach the radio antennae to their correct connectors.
NOTE If the AP-5131 is utilizing remote management antennae, a wire cover
can be used to provide a clean finished look to the installation. Contact
Motorola for more information.
