GFK-1115 6 - 1
Chapter
Demo Project
■ General Information ........................6-2
■ Required Hardware..........................6-3
■ Downloading the Demo Project .......6-4
❏ Defining the User Path .............6-4
❏ Loading the Project...................6-5
❏ Downloading/Starting the Project...6-6
■ Description of the Demo Project ......6-4
❏ General Information .................6-7
❏ Main Menu...............................6-8
❏ Value Entries............................6-9
❏ Entering a Password ............... 6-11
❏ Key Functions......................... 6-13
❏ Alarm List .............................. 6-14
❏ Error Picture........................... 6-15
■ Creating the Demo Project............. 6-16
❏ General Information ............... 6-16
❏ Creating a Project ................... 6-16
●
Preparing a Concept ........ 6-17
●
Creating a New Project .... 6-18
●
Selecting the Connections .... 6-19
●
Defining Key Assignments... 6-22
●
Creating the Pictures ....... 6-23
●
Defining the Text Groups..... 6-51
●
Binding Pictures................. 6-52
●
Editing the Alarm System .... 6-58
●
Activating the Alarm System 6-60
●
Editing the Connections....... 6-61
❏ Compiling the Project............. 6-64
❏ Errors ..................................... 6-64
6
