GFK-1115 Chapter 4 Configuring Communication with the PLC 4 - 11
4
Table 4 - 2. Panel to PLC Interface Connections for Genius Protocol
Module Interface
Series 90-30 Genius bus interface module, found
on one of the following backplanes:
5-slot backplane with built-in CPU (Model 311)
10-slot backplane with built-in CPU (Model 321)
5-slot backplane with built-in CPU (Model 313)
10-slot backplane with built-in CPU (Model 323)
5-slot backplane with modular CPU (Model
331/340/341/351)
10-slot backplane with modular CPU (Model
331/340/341/351)
GCM, IC693CMM301
GCM+, IC693CMM302
GBC-30, IC693BEM331
Series 90-70 Genius bus interface module:
Processor 80C186: Models 731, 732, 771, 772
Processor 80386DX: Models 780, 781, 782, 788,
789
Processor 80486DX: Models 914, 915, 915, 924,
925
GBC-70, IC697BEM731
Series Six Genius bus interface module GBC with diagnostics , IC660CBB902
GBC without diagnostics , IC660CBB903
Series Five Genius bus interface module GBC , IC655BEM510
Table 4 - 3. Panel to PLC Interface Connections for SNP
Module Interface
Power supply of the 90-30 or 90-20 series, found
on one of the following backplanes:
5-slot backplane with built-in CPU (Model 311)
10-slot backplane with built-in CPU (Model 321)
5-slot backplane with built-in CPU (Model 313)
10-slot backplane with built-in CPU (Model 323)
5-slot backplane with modular CPU (Model
331/340/341/351)
10-slot backplane with modular CPU (Model
331/340/341/351)
Series 90 Micro PLC
RS-485-compatible interface
15 pin D-type (F)
Note: This interface can not be used if there is not a
power supply in the main rack. Also, an RS-232 to
RS-422 converter (IC690ACC901
— converter with
cable) is required.
All CPUs of the 90-70 series:
Processor 80C186: Models 731, 732, 771, 772
Processor 80386DX: Models 780, 781, 782, 788,
789
Processor 80486DX: Models 914, 915, 915, 924,
925
RS-485-compatible interface
15 pin D-type (F)
Note: An RS-232 to RS-422 (IC690ACC901 —
converter with cable) is required.
CMM module CMM711 (Series 90-70) RS-232 from Port 1
RS-232 from Port 2
CMM module CMM311 (Series 90-30) RS-232 from Port 1
RS-232 from Port 2
