5 - 4 PANELWARE MMI Application Manual for GE Fanuc Genius Protocol - June 1995 GFK-1115
5
Editing/Inserting Connections
Pressing F1 Edit or F2 Ins in the Connection List window opens the Connection Definition
window, in which a connection can be entered or modified:
F4 Accept .............Saves and then closes the connection definition.
F10 Exit ................Closes the connection definition without saving.
Defining/Changing an ID
If the cursor is in the ID line, the identification code can be changed to any one to two letter-
number combination.
Defining/Changing a Connection
If the cursor is in the Connection line, a selection window can be accessed by pressing
↵ ↵
. Use the
cursor up (
↑↑
) or down (
↓↓
) keys to choose the type of connection required (Genius, SNP90 or
Internal) and press
↵ ↵
to insert it in the Connection Definition window.
