PANELWARE MMI Application Manual for GE Fanuc Genius Protocol -
June 1995
GFK-1115
5
Table 5 - 4. - Continued
Word s.
→
Negative values are limited to 0.
→
WORD
*
←
Values higher than 32767 are limited to 32767.
←
Word s.
→
No conversion.
→
INT
*
←
No conversion.
←
Word s.
→
Word s. is copied to the lower word. For a negative value, the
upper word is filled with FFFF (hexadecimal). For a positive value,
the upper word is filled with 0.
→
DINT
←
Values higher than 32767 are limited to 32767. Values lower than
-32768 are limited to -32768.
←
Long u.
→
No conversion.
→
DWORD
←
No conversion.
←
Long u.
→
Values higher than 2147483647 are limited to 2147483647.
→
DINT
←
Negative values are limited to 0.
←
Long s.
→
Negative values are limited to 0.
→
DWORD
←
Values higher than 2147483647 are limited to 2147483647.
←
Long s.
→
No conversion.
→
DINT
←
No conversion.
←
Float
→
No conversion.
→
FLOAT
←
No conversion.
←
String
→
For odd string lengths, a null byte is added to the end.
→
STRING
←
No conversion.
←
* For PLC addresses in group 2 ensure that the offset of the address meets the
following condition: (Offset - 1) must be 0 or a multiple of 8
