2 - 4 PANELWARE MMI Application Manual for Genius Protocol - June 1995 GFK-1115
2
Table 2 - 1. - Continued
Shock conforms to IEC 68-2-27
15g equivalent, 150 m/sec 2 , 11 msec, 3 axes (positive and
negative)
Vibration conforms to IEC 68-2-6
1g equivalent,
10-58 Hz; 0.075 mm
58-150 Hz; 9.8m/sec 2
20 cycles per axis
Processor Motorola 68302 @ 16 MHz
24 VDC power
requirements
(typical) 185 mA, 24 VDC
260 mA, 18 VDC (minimum power voltage)
150 mA, 30 VDC (maximum power voltage)
Sealing NEMA 12 and IP54 when properly mounted in a Panel
Noise immunity conforms to IEC 801.2; IEC 801.3; IEC 801.4
