LEVEL INDICATOR
The audio level indicator moves up and down to indicate the changes in the headphone level adjustments. The level
measured in decibels is displayed below the level indicator.
VU METER
The VU meter displays the headphone indicators, the limiter indicator, the +48 V phantom power indicator, the audio
channel numbers, and the audio signal levels.
BOTTOM BAR
The headphone bottom bar allows you to adjust the headphone volume.
Press the button below VOL
▼
to reduce the headphone volume
Press the button below VOL
▲
to increase the headphone volume
Refer to the
section for more information about the headphone features.
