PEAKING PEAKING MODE
The Peaking Peaking mode emphasizes the edges, and it also highlights them by using a selectable color.
Example of monitored image in Peaking Peaking mode:
TIMECODE
Timecode provides a mechanism to reference frame timing from the camera's recorded clips to other devices like
cameras and audio recorders. Some devices can also gather other data like lens metadata or camera orientation that is
referenced by Timecode to merge the data back together in post-processing.
V-RAPTOR 8K V V provides two separate Timecode concepts: Time of Day (TOD) and Edgecode. Both TOD and
Edgecode are stored in the R3D file. The user can select which Timecode displays on the
LCD by setting the preference
in Timecode Display Mode .
TIME OF DAY
TOD Timecode reflects the time and date the camera recorded each frame. V-RAPTOR 8K V V synchronizes the TOD
Timecode to an external Timecode generator (when one is connected to the
Extension Port ) or synchronizes to the
internal real-time clock of the camera.
SETTING UP TOD TIMECODE
To set up TOD Timecode on the camera, perform the following:
1. Open the Audio / Timecode menu: Menu > Audio / TC :
