User’s Manual of WGSD-8020
195
RADIUS Accounting Statistics
The statistics map closely to those specified in RFC4670 - RADIUS Accounting Client MIB.
Use the server select box to switch between the backend servers to show details for.
Packet Counters
RADIUS accounting server packet counter. There are five receive and four transmit counters.
Direction Name RFC4670 Name Description
Rx Responses radiusAccClientExtResponses
The number of RADIUS packets (valid or
invalid) received from the server.
Rx
Malformed
Responses
radiusAccClientExtMalformedResponses
The number of malformed RADIUS packets
received from the server. Malformed packets
include packets with an invalid length. Bad
authenticators or or unknown types are not
included as malformed access responses.
Rx
Bad
Authenticators
radiusAcctClientExtBadAuthenticators
The number of RADIUS packets containing
invalid authenticators received from the
server.
Rx Unknown Types radiusAccClientExtUnknownTypes
The number of RADIUS packets of unknown
types that were received from the server on
the accounting port.
Rx Packets Dropped radiusAccClientExtPacketsDropped
The number of RADIUS packets that were
received from the server on the accounting
port and dropped for some other reason.
Tx Requests radiusAccClientExtRequests
The number of RADIUS packets sent to the
server. This does not include
retransmissions.
Tx Retransmissions radiusAccClientExtRetransmissions
The number of RADIUS packets
retransmitted to the RADIUS accounting
server.
Tx
Pending
Requests
radiusAccClientExtPendingRequests
The number of RADIUS packets destined for
the server that have not yet timed out or
received a response. This variable is
incremented when a Request is sent and
decremented due to receipt of a Response,
timeout, or retransmission.
Tx Timeouts radiusAccClientExtTimeouts
The number of accounting timeouts to the
server. After a timeout, the client may retry to
