User’s Manual of WGSD-8020
186
•
Last Source The source MAC address carried in the most recently received EAPOL frame for
port-based authentication, and the most recently received frame from a new
client for MAC-based authentication.
•
Last ID
The user name (supplicant identity) carried in the most recently received Resp/ID
EAPOL frame for port-based authentication, and the source MAC address from
the most recently received frame from a new client for MAC-based
authentication.
4.11.6 802.1X Statistics
This page provides detailed IEEE 802.1X statistics for a specific switch port running port-based authentication. For MAC-based
ports, it shows selected RADIUS statistics, only. Use the port select box to select which port details to be displayed. The 802.1X
and MAC-Based Authentication Statistics screen in Figure 4-11-10 appears.
Figure 4-11-10 802.1X Statistics Port 1 page screenshot
The selected port belongs to the currently selected stack unit as reflected by the table header.
„ EAPOL Counters
These counters are not available for MAC-based ports.
Supplicant frame counter statistics. There are seven receive frame counters and three transmit frame counters.
