Setup
20
Step 4: Create Profiles
Settings for particular connections are contained in profiles on the Eicon 1550/1551.
Note: When you change protocols for the VHSI interface, all profile information is lost. To avoid having to
re-enter configuration information, choose the protocol first, as described in
As profiles contain many settings, you may find it useful to fill out the
on page 142 in order to determine your settings before making changes.
Creating a Profile
1.
From the menu, click the ‘Connection’ link. The ‘Connection Profiles’ page appears.
As no profiles yet exist, the only section on this page is an area to create a new profile.
2.
To add a profile, enter the name in the ‘Name’ field, select the port, then click the
‘Done’ button.
Note:
The ISDN port (available on the Eicon 1551 only) is used mainly for backup
purposes.
‘Name’ field
‘Port’ setting
