Web Interface Settings Glossary 103
Protocol Menu (VHSI Tree) (X.25)
These parameters are only available when the protocol is set to X.25.
Node Type
Defines if the Eicon 1550/1551 functions as DTE (Data Terminal Equipment) or DCE
(Data-Circuit terminating Equipment). Consult your network subscription for the proper
setting.
Default: DTE.
• DTE: Use when connected to an X.25 network, or to another computer configured as
DCE.
• DCE: Use when connected to another computer configured as DTE.
Local DTE Address
Defines the X.25 DTE address assigned to the Eicon 1550/1551.
Range: 1-15 digits.
Default Window Size
Defines the default X.25 window size.
Range: 1-7. Default: 2.
Maximum Window Size
Defines the maximum X.25 window size.
Range: Default window size to 7. Default: 7.
Packet Format
Defines the type of packets supported. Consult your network subscription to see if you
can make use of Extended Packet features. This parameter affects Window size.
• Basic: Supports only the standard packets used on all networks.
• Extended: Supports the use of extended clearing, call user data, and other features
available only on certain networks.
