Configuration Worksheets 149
Dialer Parameters Worksheet — Hayes AT
The following settings are available when configuring Hayes AT.
Parameter Options/Range Default Value
Enable Answering Enable, Disable Enable
Allow retry Enable, Disable Enable
Retry limit Range: 1-9 4
Delay between retries Range: 0-65 5
Speed 1200-230400 115200
Bits/Char Values: 7 or 8 7
Parity
Primary Number ATDT, ATDP
Secondary Number ATDT, ATDP
Max delay to establish connection 15-65 30
Hangup delay 0-65 2
DSR (on->off) transition delay 0-65 2
RI to DTR delay 0-30000 1000
DSR loss delay 0-10000 1500
Max delay between rings 1-9000 5000
Min. DSR (on) state delay before
going off hook 0-4000 2000
