Configuration Worksheets 150
Dialer Parameters Worksheet —V.25Bis
The following settings are available when configuring V.25Bis.
Parameter Options/Range Default Value
Enable Answering Enable, Disable Enabled
Allow retry Enable, Disable Enabled
Retry limit 1-9 4
Delay between retries 1-9 4
Primary number N,I,S
Secondary number N,I,S
Max delay to establish connection 15-65 30
Hangup delay 0-65 2
DSR (on->off) transition delay 0-65 2
RI to DTR delay 0-30000 1000
DSR loss delay 0-10000 1500
Max delay between rings 1-9000 5000
Min. DSR (on) state delay before going off
hook 0-4000 2000
Send a command message delay 200-4000 200
