Setup
19
Step 3: Select the VHSI Protocol
Before you begin creating connection profiles, including any backup profiles, you
should verify the protocol setting for the VHSI port (set to ‘X.25’ by default). This is due
to the fact that all connection profiles are deleted when the protocol is changed.
Note: Configuration settings can be saved to a file on your hard drive. This is useful if you have many
connection profiles already defined but need to change the VHSI protocol. See
on page 46 for more information.
1.
From the menu (at the left of the screen), click on the small ‘+’ next to ‘VHSI Port’ to
expand the VHSI Port group, then click the ‘Protocol’ link.
2.
From the ‘Protocol’ drop-down menu, select a protocol.
3.
If you changed the protocol, click the ‘Save’ button, located at the bottom right of the
web page, when finished. You may have to scroll down in order to locate the button.
Note:
If you do not click ‘Save’, the changes will be lost when you move to another
page.
‘Protocol’ link
‘Protocol’
drop-down
menu
