Configuration Worksheets 147
VHSI Port Worksheet
The following settings are available when configuring VHSI.
Parameter Options/Range Default Value
Line Interface Leased, Dial Leased
Duplex Full, Half Full
Multidrop Point-to-Point, Multi-Point Point-to-Point
Modem Interface Autodetect,
RS-232, V.24 Autodetect
Data Encoding NRZ, NRZI, DPLL, FMO, FM1 NRZ
Clocking EXTERNAL, INTERNAL,
EXTDPLL, INTDPLL EXTERNAL
Line Speed 2400, 3600, 4800, 7200, 9600,
14400, 19200, 38400, 48000,
56000, 57600, 64000,
768000, 896000, 1000000,
1024000, 1152000, 1280000,
1408000, 1536000, 1544000,
1600000, 2048000 64000
DCD (off) - > RTS (on) delay 0-9999 0
RTS (on -> off) maximum delay 0-9999 0
DCD (on-> off) maximum delay 0-9999 0
Tx idle timeout (on-> off)
maximum delay 0-9999 0
