SMA Solar Technology AG Electrical Connection
Installation Guide WB36TL_50TL-IEN102011 35
4. Push the threaded joint to the thread and screw into place.
☑ The DC plug connectors are now assembled and can be connected to the inverters, as
described in section 5.4.4 ”Connecting the Windy Boy Protection Box (DC)” (page 37).
☑ If the conductor is not visible in the hollow
cavity, the cable is not in the correct
position.
• Loosen the clamping clip using a
screwdriver.
• Remove cable and start again from step 1.
Result Action
